Silicon’s semiconducting properties make it one of the most critical elements in the semiconductor industry. However, before manufacturers use it in various electronic applications, it goes through a series of processes during silicon manufacturing.

Silicon Manufacturing Reduction Process

Silicon Manufacturing Process

The Reduction Process

Silica sand and carbon materials are prepared in batches and weighed before being placed into a submerged electric arc furnace. A typical batch contains around 453 kg of gravel and chips and 250 kg of coal.

As an electric current passes through the electrodes on the lid of the furnace, it forms an arc that generates heat up to 4,000°F or 2,350°C. The high temperatures trigger a reaction where the oxygen is removed, leaving behind silicon and carbon monoxide. The entire reduction process takes approximately six to eight hours.

A reduction of the amount of calcium and aluminum impurities occurs via oxygen treatment while silicon is in its molten state. Silicon metal typically contains 98.5 % to 99.99% silicon with trace amounts of calcium, iron, and aluminum.

Cooling Process

Slag refers to the oxidized material that’s poured off into containers and cooled. The silicon metal is cooled in large cast-iron trays that measure about 2.4 m across and 20 cm deep. After the cooling process is completed, manufacturers dump the metal from the mold into a truck to break it up in preparation for storage.

Crushing Process

They measure the weight of the metal before they dump it into the storage pile. Next, the metal is sized via the crushing process using jaw or cone crushers. The sizes are based on the specifications of the customer.

Packaging Process

In most cases, silicon metal is packed in large sacks or wooden boxes weighing 1,361 kg. On the other hand, silicon in powder form is packaged in paper bags or plastic pails weighing up to 23 kg, steel drums weighing 227 kg, or large boxes weighing 1,361 kg.

Silicon Manufacturing Polishing Process
